5-Gallon High-Tech Iwagumi Aquascape (Intermediate)
A 5-gallon nano Iwagumi: a few stones, one carpet, and a great deal of deliberate empty water. It is a nano tank, where every decision shows. Pressurised CO2, active soil and real light — faster growth, more colour, and a tank that needs you every week. 2 plant species, Dragon Stone, and 2 livestock groups checked against each other for compatibility — every quantity below sized to 5 gallons and every plant chosen for an intermediate.
Generate this exact design in the studio →
More than a design — your whole aquarium, handled
Everything below is generated for this 5-gallon nano Iwagumi build — 2 plants, 2 livestock groups, and gear sized to 5 gallons. The studio does the same for your tank, free.
Hardscape — what to buy and how to place it
Dragon Stone is warm ochre and deeply pitted, full of hollows and honeycombed pockets. Dragon Stone is baked clay and chemically inert, so it will not move your pH or hardness in either direction. Rinse and scrub it hard before it goes in — dry Ohko sheds a fine clay dust that will cloud the water for days. The hollows are planting pockets: press moss or a small epiphyte into them and the stone disappears into the scape as it grows.
At 5 gallons, plan on three pieces in clearly unequal sizes. An odd count is easier to compose, and one piece should obviously lead — a group of similar-sized pieces spread evenly across the tank is the most common way a first scape goes flat.
Iwagumi is built from named roles, not from a pile. The Oyaishi is the main stone: the largest, set on a third of the tank width rather than the centre, leaning very slightly off vertical. The Fukuishi supports it from the opposite side at roughly two-thirds its size, and the Soeishi is smaller again and sits close to the Oyaishi. Odd numbers only, and no two stones the same size.
Substrate
Aqua soil (e.g. ADA Amazonia / UNS Controsoil), built to about 2–3" and sloped higher at the back. Active soil buffers soft, slightly acidic water and feeds roots. Slope higher at the back for depth.
Fresh aqua soil leaches ammonia for the first one to three weeks. That is normal and it is also why you do not stock a high-tech tank early: run it, change a good volume of water two or three times in that first fortnight, and wait for ammonia and nitrite to read zero before any livestock goes in.
Because this plan carpets the foreground, keep the front of the substrate shallow and level — around an inch is plenty — and save the depth for the back. Carpets are planted into a flat bed in small clumps a couple of centimetres apart, and they spread sideways to meet; planting them dense enough to look finished on day one wastes plants and traps debris.
Plant list & placement
Plant back to front, into damp substrate with the tank only part-filled — it is far easier than fighting buoyancy in a full tank. Spiky Moss is the tallest thing in this plan at around 3", so it sets your back row and everything else steps down in front of it.
Riccia is the fast grower here — bright pearling carpet when tied down; needs high light/CO2. Expect to be cutting it weekly once it establishes. Top the stems, replant the healthy tops in the same group and discard the old bases; a stem bed replanted from tops stays dense, while one left to grow on goes bare at the bottom.
Spiky Moss is an epiphyte and must never be buried. Tie or glue the rhizome onto your hardscape and leave it fully exposed — a buried rhizome rots, and it is the single most common way a beginner loses an Anubias or a Java fern. Only the roots may touch the substrate.
Stocking
Blue Dream Shrimp and Batik Nerite Snail are the clean-up crew, and in a planted tank they earn their place — grazing biofilm and soft algae off the hardscape and leaves faster than you can. Add them last, once the tank has some algae to eat, and drip-acclimatise rather than dumping the bag in.
- The Spiky Moss is in this plan for the shrimp, not for the look. Newly hatched Blue Dream Shrimp are small enough for almost anything to eat, and a thick mat is the only cover fine enough to hide in — it is what decides whether the colony grows or just holds on. Let it fill in before you add fish.
With Blue Dream Shrimp in the tank the constraint is predation rather than aggression: adult shrimp are safe here, but assume any fish that fits a shrimplet in its mouth will eat one, so give the shrimp moss or dense planting to breed into. Every pairing was run through Skapelab’s compatibility engine and anything returning even a caution was swapped out rather than published. Check any substitution you make there before you buy.
Equipment
| Category | Recommendation | Notes |
|---|---|---|
| Filtration | Fluval 107 Canister Filter | ~$88–118 |
| Co2 | AQUATEK Mini CO2 Regulator + 20oz Paintball | ~$65–88 |
| Heating | Fluval E50 Electronic Heater | ~$28–38 |
| Testkit | API Freshwater Master Test Kit | ~$28–42 |
| Water treatment | Seachem Prime 500ml | ~$12–20 |
| Bacteria | Seachem Stability 250ml | ~$8–14 |
What the first two months look like
| Week 1 | Hardscape in, planted, filled and running with no livestock. CO2 comes on an hour before the lights and off an hour before they go out; aim the drop checker at a green, never yellow. Keep the photoperiod short, around six hours, while the plants root. |
| Weeks 2–4 | Cycling, and the ugly phase. Brown diatom dust on the glass and hardscape is normal in a new tank and passes on its own once silicates are used up; the fresh soil is also still releasing ammonia, so keep changing water. Some plants will melt back and regrow in their submersed form — that is conversion, not death, so trim the mush and leave the roots. Do not stock until ammonia and nitrite both read zero. |
| Weeks 4–6 | Stocking begins, a few animals at a time with a fortnight and a water test between additions. In a tank this small there is no margin — one full stocking list added at once is the classic way a nano crashes. The carpet should be visibly running now; resist raising the light to hurry it. |
| Months 2–3 | The scape fills in and the routine settles into the schedule below. Judge the design now rather than on day one; a planted tank is not finished until it has grown into itself. |
Care schedule
| Daily | Feed lightly — as much as they clear in a minute or two — and take ten seconds to count heads and look at the plants. Check the drop checker is green before the lights come on. |
| Weekly | 40% water change — about 2 gallons on this tank — using a jug and a length of airline. Dose your macros and micros after the change, not before. Wipe the glass and check the CO2 cylinder pressure. |
| Monthly | Rinse filter media in old tank water — never under the tap, which kills the bacteria colony you spent six weeks growing. Test KH, GH, pH and nitrate. Check for anything the weekly routine keeps missing behind the hardscape. |
| Every few months | Replace the CO2 diffuser membrane, check the regulator has not crept, and pull the deepest stems for a hard replant. Lights lose output long before they fail — plan on replacing LEDs or bulbs on a schedule, not on symptoms. |
Make it yours
This is a starting point. Open it in the studio to swap plants, resize to your tank, and get a hand-illustrated render, placement diagram, and shopping list — free.
